Friday, 24 May 2019

PHDays - Fuzzing 101

So, this year (2019) me along with my colleague Zubin delivered a workshop in PHDays 9 on fuzzing. This workshop was mainly focused on an introduction to fuzzing using AFL and ASAN.

The prime focus of the workshop would be around the following areas: Fuzzing using SPIKE, blind and input-based fuzzing (AFL), finding memory bugs using ASAN with AFL integration, protocol fuzzing (HTTP, FTP, SMTP). Then we concluded the workshop by showcasing multiple bugs found during their research.

Slides: Fuzzing-101_PHDays.pdf

Ubuntu OVA file: Ubuntu_Fuzzing101.ova  : Size: 4.x GB, 4GB RAM, 40 GB HD.
Username: PHDays
Password: E@sy

We have further plans to take an advanced workshop on this in other conferences. Fork this repository on GitHub. If you want to read more about fuzzing here is what I wrote while fuzzing WebKit.

Sunday, 12 May 2019

Path Traversal in WEBrick via SYMLINK

Summary: The WEBrick gem 1.4.2 for Ruby allows directory traversal if the attacker once had local access to create a symlink to a location outside of the web root directory.

NOTE: The vendor states that this is analogous to Options FollowSymlinks in the Apache HTTP Server, and therefore it is "not a problem."

Technical Observation: A path traversal issue was observed in WEBrick (WEBrick/1.4.2 (Ruby/2.6.3/)) via symlink. WEBrick serves static page for the current directory once enabled, however using symlink attacker could view data outside the hosted/running directory.

Steps to reproduce:
mkdir nothing
 cd nothing
 ln -s ../../ symlnk
 ruby -run -ehttpd . -p8080
ImpactThis would allow the attacker to view sensitive data outside the root/running directory.

Remediation: In order to solve the problem, we should simply check the absolute/real path of any user input paths and if the absolute path is outside the home directory, then return an error response, This way users will not lose the possible benefits of symbolic links.
Educating users about this behavior in the docs and probably providing a flag to disable/enable the symlinks.

After reporting this to WEBrick team, they will add below statement in WEBrick documentation.

"WEBrick can be run as a production server for small loads. Be aware that symlinks might allow users to view data outside of the designated root directory, such as for the Apache webserver with the FollowSymlinks option enabled".


Apart from WEBrick, I reported the same vulnerability in one of the npm module (simplehttpserver) via H1 but went duplicate. Also, the issue exists in python modules `SimpleHTTPServer` and `http.server` but python security team says these servers should not be used in production and they have already mentioned it in their documentation.

I also found PHP -S module and hhvm protect against this vulnerability by default, a disputed CVE-2019-11879 was assigned to this issue against WEBrick.

Friday, 26 April 2019

XSS everywhere

Summary: The "Chat Room" portlet demo that ships with the Apache Pluto Tomcat bundle contains a persistent Cross-Site Scripting (XSS) vulnerability. Specifically, if an attacker can input raw HTML markup into the "Name" or "Message" input fields and submits the form, then the inputted HTML markup will be embedded in the subsequent web page.

Versions Affected:
Apache pluto 3.0.0, 3.0.1

- Start the Apache Pluto Tomcat bundle
- Visit http://localhost:8080/pluto/portal/Chat%20Room%20Demo
- In the name field, enter:
     <input type="text" value="Name field XSS></input>
- Click Submit
- In the message field, enter:
     <input type="text" value="Message field XSS></input>
diff --git demo/chat-room-demo-portlet/pom.xml demo/chat-room-demo-portlet/pom.xml
index e37d88ddb..1e4b2e4dd 100644
--- demo/chat-room-demo-portlet/pom.xml
+++ demo/chat-room-demo-portlet/pom.xml
@@ -43,6 +43,10 @@
+  <dependency>
+   <groupId>org.apache.commons</groupId>
+   <artifactId>commons-lang3</artifactId>
+  </dependency>
   <!-- for eclipse JSP tooling purposes -->
diff --git demo/chat-room-demo-portlet/src/main/java/org/apache/portals/pluto/demo/chat/ demo/chat-room-demo-portlet/src/main/java/org/apache/portals/pluto/demo/chat/
index df82f6a4a..b9f61cf02 100644
--- demo/chat-room-demo-portlet/src/main/java/org/apache/portals/pluto/demo/chat/
+++ demo/chat-room-demo-portlet/src/main/java/org/apache/portals/pluto/demo/chat/
@@ -18,6 +18,8 @@
+import org.apache.commons.lang3.StringEscapeUtils;
 import java.util.ArrayList;
 import java.util.Collections;
 import java.util.List;
@@ -66,7 +68,7 @@ public class ChatHistory {
       StringBuilder txt = new StringBuilder(128);
       synchronized (messages) {
          for (String msg : messages) {
-            txt.append("<p>").append(msg).append("</p>\n");
+            txt.append("<p>").append(StringEscapeUtils.escapeHtml4(msg)).append("</p>\n");
       return txt.toString();
diff --git demo/chat-room-demo-portlet/src/main/java/org/apache/portals/pluto/demo/chat/ demo/chat-room-demo-portlet/src/main/java/org/apache/portals/pluto/demo/chat/
index 50ac6befd..6eaa6236b 100644
--- demo/chat-room-demo-portlet/src/main/java/org/apache/portals/pluto/demo/chat/
+++ demo/chat-room-demo-portlet/src/main/java/org/apache/portals/pluto/demo/chat/
@@ -19,6 +19,8 @@
+import org.apache.commons.lang3.StringEscapeUtils;
 import javax.inject.Inject;
 import javax.portlet.annotations.RenderMethod;
@@ -48,7 +50,7 @@ public class HelloWorldRender {
       txt.append("<h3>Hello \n");
       // Get the name from the bean. If it hasn't been set, just greet the world.
       if (nameBean.getName() != null) {
-         txt.append(nameBean.getName());
+         txt.append(StringEscapeUtils.escapeHtml4(nameBean.getName()));
       } else {
* Uninstall the ChatRoomDemo war file
- or -
* migrate to version 3.1.0 of the chat-room-demo war file

Later CVE-2019-0186 was assigned to this issue and here is the advisory from apache pluto [1] [2].

Wednesday, 17 April 2019

Code execution - Evernote

A local file path traversal issue exists in Evernote 7.9 for macOS which allows an attacker to execute arbitrary programs.

Technical observation:
A crafted URI can be used in a note to perform this attack using file:/// as an argument or by traversing to any directory like

Since Evernote also has a feature of sharing notes, in such a case an attacker could leverage this vulnerability and send crafted notes (.enex) to the victim to perform further attacks.

A patch for this issue was released in Evernote 7.10 Beta 1 and 7.9.1 GA for macOS [MACOSNOTE-28840]. CVE-2019-10038 was assigned to this issue.

Saturday, 23 February 2019

Fuzzing Webkit

Hi Internet,

Summary: While fuzzing webkit the UIProcess subsystem in WebKit, as used in WebKitGTK through 2.23.90 and WebKitGTK+ through 2.22.6 and other products, does not prevent the script dialog size from exceeding the web view size, which allows remote attackers to cause a denial of service (Buffer Overflow) or possibly have unspecified other impact, related to files such as UIProcess/API/gtk/WebKitScriptDialogImpl.cpp and UIProcess/API/gtk/WebKitWebViewGtk.cpp.

System Specifications: My setup was done using Ubuntu 16.04 LTS (my base OS). You can use macOS as well as it has Xcode and Safari by default. If you are using Ubuntu in VM please allocate as much memory and CPUs as possible.

Source Code: You can download webkit source code from here or simply git:

cmd: git clone git:// webkit

Before you build webkit make sure to install necessary dependencies, it will require a lot of trial and error while installing the dependencies but perseverance always wins.

cmd: ./Tools/gtk/install-dependencies

Build: To build webkit in macOS use,

cmd: ./Tools/Scripts/build-webkit

Integrating libFuzzer: I have used libFuzzer in this case to fuzz webkit you can use any alternative out there, you can also enable ASAN or MSAN flags to see runtime bugs while building the packages.

cmd:   mkdir build
          cd build
          CC=clang CXX=clang++ cmake -GNinja -DFUZZ=1 ../


cmd: -DCMAKE_CXX_FLAGS="-fsanitize=address  -fsanitize=leak -g"

The compilation of webkit is a time and memory consuming task, make sure you don't run out of patience. Once successfully build you can test by running safari or providing the path of any webkit application.

cmd: ./Tools/Scripts/run-safari

cmd: ./Tools/Scripts/run-webkit-app

Start fuzzing: From the /build directory you can run fuzzer[1]

cmd: ./fuzz/cert -max_len=1000 -jobs=32 -workers=32 ../fuzz/cert_corpus/

This is one of the methods to fuzz webkit, while running the libFuzzer continuously for multiple days, I did not observe any crashes or hangs. The reason being there are many researchers out there who have fuzzed webkit and reported several bugs in past. (and I've just started..)

Now what?

I started researching more about webkit and found out that "epiphany-browser" utilizes the webkit browser engine, I thought that this browser might have been untouched in terms of fuzzing by a lot of the researchers, hence this time I used AFL to fuzz epiphany. For test-cases I used domato from google project zero (A DOM fuzzer) to provide input to AFL

Source code: Epiphany Browser

With AFL:

cmd: mkdir build && cd build
        CC=afl-gcc meson --default-library=static ../
        AFL_HARDEN=1 ninja

Once done you can start fuzzing epiphany with AFL.

cmd: afl-fuzz -i in/ -o out/ binary @@

I let AFL running for 4 days and observed 16 crashes, among those 7 were unique crashes and 4 were hangs (Happy face). I started analyzing the observed hangs. One of the PoC from AFL freezes the epiphany browser by causing the UI process to terminate and below debug traces were left.
(epiphany:4423): Gdk-WARNING **: Native Windows wider or taller than 32767 pixels are not supported
Gdk-Message: Error 71 (Protocol error) dispatching to Wayland display
Looking at the above traces I came to the conclusion that the native UI window cannot open dialog boxes more than 32767 pixels.

Rather than using AFL PoC every time, I generated my own test-case as I just needed to pass some random characters in native UI windows to produce this hang.
   var a = '';
   for (var i = 1; i <= 5000; i++)
       a += 'A';
You can run the above JS on a vulnerable version of epiphany browser to test this issue. I went ahead and found that WebKitScriptDialogGtk.cpp along with WebKitScriptDialogImpl.cpp &  WebKitWebViewGtk.cpp from webkit source code are responsible for this issue and figured out the below snippet of code from WebKitScriptDialogGtk.cpp was the source of the vulnerability.
static GtkWidget* webkitWebViewCreateJavaScriptDialog(WebKitWebView* webView, GtkMessageType type, GtkButtonsType buttons, int defaultResponse, const char* primaryText, const char* secondaryText = nullptr)
    GtkWidget* parent = gtk_widget_get_toplevel(GTK_WIDGET(webView));
    GtkWidget* dialog = gtk_message_dialog_new(WebCore::widgetIsOnscreenToplevelWindow(parent) ? GTK_WINDOW(parent) : nullptr,
        GTK_DIALOG_DESTROY_WITH_PARENT, type, buttons, "%s", primaryText);
    if (secondaryText)
        gtk_message_dialog_format_secondary_text(GTK_MESSAGE_DIALOG(dialog), "%s", secondaryText);
    GUniquePtr<char> title(g_strdup_printf("JavaScript - %s", webkitWebViewGetPage(webView).pageLoadState().url().utf8().data()));
    gtk_window_set_title(GTK_WINDOW(dialog), title.get());
    if (buttons != GTK_BUTTONS_NONE)
        gtk_dialog_set_default_response(GTK_DIALOG(dialog), defaultResponse);

    return dialog;
After that I submitted this bug in webkit, the issue was patched and  CVE-2019-8375 was assigned which states "This allows remote attackers to cause a denial of service (Buffer Overflow) or possibly have unspecified other impact."

Metasploit module: It is a denial of service vulnerability and you can simply use RemoteHTTPServer to write a quick MSF module for this.
In the past I have created BFuzz (DOM Fuzzer) which automates the task of generating multiple test-cases using domato, which can be further used to fuzz browsers of your choice.

However, there are still 7 unique crashes and 3 hangs which I haven't analyzed yet, that may be covered in one of my upcoming blog posts.
